Delta Tau

Delta Tau's advanced motion control systems are scalable and capable of high axis counts (128+) and incorporating customized control algorithms.

SPEAK WITH A SPECIALIST TODAY

CK3M Multi-Axis Motion Controller

Maximize your machine's performance: Performing precise linear motor drive control and nanoscale positioning, the PMAC (Programmable Multi Axis Controller) has been appreciated by manufacturers of semiconductor manufacturing equipment and other leading-edge equipment. Omron now offers a next generation motion controller CK3M that packs PMAC’s superior motion control capability, multi-vendor connectivity, and flexible development capability into its compact design. The CK3M removes constraints and barriers and maximizes your machine’s capabilities.

CK3M Multi-Axis Motion Controller

The CK3A Amplifier, combined with the flexibility of Power PMAC Controller and the ability to interface with various encoder feedback devices, allows the support of the following types of Motors:

  • AC/DC synchronous brushless (rotary or linear) - e.g. servo Motor.
  • DC Brushed - e.g. voicecoil actuator.
  • AC asynchronous - e.g. Induction Motor (contact support for setting up this type of Motor).



  • Basic functions - Energy discharge, dynamic braking, fan control
  • Basic Data reporting - DC bus voltage, power module temperature, firmware version
  • Dual 7-segment LED status display
  • Built-in or external shunt resistor
  • Support of low voltage main power operation

CK3E Multi-Axis EtherCAT Motion Controller

By combining global leading Delta Tau Data Systems’ Motion Control technologies, Omron can open up new applications and solutions. The CK3E is a controller designed for precise multi-axis control. You can build a system capable of controlling up to 32 axes of motion and incorporate customized control algorithms into the system. The CK3E allows you to program in C language and reuse existing software assets. The compact design saves space in machines and control panels. EtherCAT® connects servo drives, I/O, and other devices to the CK3E, reducing the number of cables.

CK3C Board Level Controller

The CK3C is a compact industrial motion and automation controller encompassing the full capabilities of Omron’s Power PMAC (Programmable Multi-Axis Controller) platform. Inherently, the CK3C is a 4-axis card expandable to 8- local and another 8- EtherCAT axes. The optional extended pins provide maximum flexibility for OEM embedded design, high-speed interface to third-party devices, and custom connectorization.

EXPLORE

DELTA TAU RESOURCES

DownloadsVideosTechnical Documents

TitleDownload Link
CK3A Data Sheet – Delta Tau Omron

CLICK TO DOWNLOAD

CK3C PMAC Controller Brochure – Delta Tau Omron

CLICK TO DOWNLOAD

CK3E Datasheet – Delta Tau Omron

CLICK TO DOWNLOAD

CK3M Multi-Axis Motion Controller – Delta Tau Omron

CLICK TO DOWNLOAD

CK3M Multi-Axis Motion Controller Brochure – Delta Tau Omron

CLICK TO DOWNLOAD

Controller Safety for Compact Applications – Omron

CLICK TO DOWNLOAD

PMAC Series Programmable Multi-Axis Controller Brochure – Delta Tau Omron

CLICK TO DOWNLOAD

Programmable Multi-Axis Controller Brochure – Delta Tau Omron

CLICK TO DOWNLOAD

Programmable Multi-Axis Controller User’s Manual – Delta Tau Omron

CLICK TO DOWNLOAD
